VOGO C130 - Smart cover
Japanese toilet seat cover.
- • Remote control handle.
- • Rounded profile.
- • Compatible with different toilet models.
(Toilet of the images not included).
FREE SHIPPING IN PENINSULA IN 24H - 48H
Defer your purchases in 3, 6, 9 and 12 months.
VOGO C-series smart covers allow you to convert your existing toilet into a Japanese-style toilet with an integrated water jet:
- · Seat compatible with various toilet models.
- · Made of ABS (Acrylonitrile Butadiene Butadiene Styrene), a thermoplastic that provides rigidity and strength.
The C130 smart cover, compared to the C120 cover, has a more rounded design, and is more suitable for most toilets.
TECHNICAL FEATURES:
- · Pure white colour with the back panel of the cover in silver colour.
- · Dimensions: 51.8 × 43.5 × 15.8 cm (L × W × H).
- · Features: Heated seat, water cleaning, warm air drying, approach sensor, flip-top lid lock and massage function among others.
- · Remote control: Remote control and via the built-in digital panel.
- · Easy installation.
- · Required pressure: 1 bar
PACKAGING:
- Cardboard box: 58 x 50 x 20 cm.
- Foam-protected interior.
- Automatic cover opening and closing with proximity sensor.
- Remote controlled opening and closing of the seat
- Female cleaning
- Male cleansing
- Water massage
- Heated drying
- Heated seat
- Self-cleaning hygienic nozzle
- Automatic deodorisation
- Cushioning for soft closing
- Night light
- Cleaning nozzle position adjustment
- Water temperature setting - 5 adjustable levels
- Drying temperature setting - 5 adjustable levels
- Seat temperature setting - 5 adjustable levels
VOGO smart lids are compatible with the following toilets:
- Toilet with vertical tank: Compatible.
- Toilet with convex tank: Compatible.
- Toilet with inset tank (wall-mounted): Compatible.
- Toilet with square tank: Compatible.
- Toilet with concave tank: Depends on model.
- Toilet with round tank: Depends on model.
To install one of the VOGO smart covers, two basic elements are required:
- • A mains water supply, which must have a pressure equal to or greater than 1 bar.
- • A 230 V socket outlet of type F, which is the European standard.
Install the toilet seat
- • Remove the cover and seat from the toilet seat you currently have installed.
- • See the picture below for the accessories included with the cover.
- • Hold down the side mounting bar, and align the toilet seat with the rectangular mounting plate. Push the toilet seat into the mounting plate.
Install water supply hose
- • Close the water supply valve (Angle spanner).
- • Thread the 4 screwed points of the inlet valve and wrap it with adhesive tape, then connect it to the water outlet of the tap and tighten.
- • Connect the filter to the inlet of the water inlet valve and wrap it, then connect it to the water inlet valve and tighten.
- • Connect the hose that allows the filtered water to pass through.
Make sure that all the connections are correctly made and open the supply valve (square key).
Parameters to be taken into account:
- • Rated frequency: 50-60 HZ
- • Power rating: 1250 W (when the water temperature is below 15 ℃, the heater reaches full load).
